Rear view
a Protruding lid for holding when
moving the machine (see arrows)
b Mains connection cable
c Hose for external drainage of
condensed water
d Accessories for connection to a sink
drain outlet
Transporting the dryer
When moving the dryer, hold it by the
lid where it protrudes to the rear. To
manoeuvre the machine out of its
packing case to its installation site, hold
it by the front feet as well as by the
edge of the lid where it protrudes to the
rear of the washing machine.
,
Only transport the dryer as
shown in the following illustrations.
,
If transporting the dryer at an
angle, only tip towards the left side.
,
If the tumble dryer has not been
transported as described, then it
must be left to stand for at least 1
hour before
it is connected to the
electricity supply. Otherwise the
heat pump can be damaged.
Installation and connection
42
