Miele W 1714 User Manual

Before using the machine for the first
time ensure that it is correctly
installed and connected. See
"Installation and connection". Also
check that the drain filter is securely
tightened to prevent the risk of water
leaks during use.
This washing machine has
undergone a thorough functional test
in the factory and there will be some
residual water in the drum from this
process.
For safety reasons, spinning is not
possible until the machine has been
prepared for using for the first time. To
activate the spinning function you must
run a wash programme without laundry
and without detergent.
Using detergent could result in an
excessive build-up of foam.
This also activates the ball valve. The
ball valve prevents detergent escaping
from the suds container into the sump
during a wash programme, thus making
maximum use of the detergent.
^
Press the I-On/0-Off button in.
If the washing machine is being
switched on for the first time, the
welcome screen will appear.
The welcome screen will appear in
the display every time the machine is
switched on until a programme
lasting longer than 1 hour has been
completed.
Setting the language
You will be asked to select the
language you require for the display. It
is possible to change the language at
any time via the programmable
functions.
! deutsch
^
If the language shown is not the one
you want, select the language you do
want by turning the programme
selector. Confirm your selection by
pressing the Start/Stop button.
Reminder to remove transit bars
To avoid the risk of damage, the
transit bars must be removed before
the machine is used for the first time.
See "Installation and connection" for
instructions on how to do this.
^ After removing the transit bars (if this
has not already been done by your
fitter), press the Start/Stop button.
Running your first programme
Run a Cottons 60°C programme without
any laundry and without detergent.
^
Open the stopcock.
^
Press the Start/Stop button.
^
At the end of the programme switch
the machine off.
The machine is now ready for use.
Before using for the first time
12

Miele W 1714 Specifications

General

Current	10 A
Connected load	2300 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (typical)	2100 W
Water consumption per cycle	47 L
Energy consumption washing per cycle	1.02 kWh
Door color	Gray
Door hinge	-
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Drum capacity	6 kg
Cycle time (max)	109 min
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (wash)	- dB
Washing class	A
Annual water consumption washing	9400 L
Annual energy consumption washing	204 kWh

Weight and Dimensions

Depth	634 mm
Width	595 mm
Height	850 mm
Weight	99000 g
