Miele W 1714 User Manual

Cleaning the water inlet filters
The washing machine has two filters to
protect the inlet valves.
These filters should be checked every
six months or so, or more often if there
are frequent interruptions to the water
supply.
To clean the filter in the union in the
open end of the inlet hose:
^
First turn off the stopcock.
^
Unscrew the threaded union
connecting the free end of the inlet
hose to the stopcock.
^
Remove rubber seal 1 from the
recess.
^
Using pointed pliers, take hold of
plastic filter bar 2, remove the filter
and clean it.
^
Put the filter and seal back in the
reverse order and reconnect the
hose.
^
Turn on the stopcock and check the
connection is watertight. If it leaks,
tighten the connection.
To clean the filter in the water inlet
valve:
^
Using pliers, carefully loosen the
ribbed plastic nut on the inlet valve
and unscrew.
^ Use pointed nose pliers to withdraw
the plastic filter by the bar (see
illustration). Clean, put back and
secure.
The two filters must be put back in
place after cleaning.
Cleaning and care
32

Miele W 1714 Specifications

General

Current	10 A
Connected load	2300 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (typical)	2100 W
Water consumption per cycle	47 L
Energy consumption washing per cycle	1.02 kWh
Door color	Gray
Door hinge	-
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Drum capacity	6 kg
Cycle time (max)	109 min
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (wash)	- dB
Washing class	A
Annual water consumption washing	9400 L
Annual energy consumption washing	204 kWh

Weight and Dimensions

Depth	634 mm
Width	595 mm
Height	850 mm
Weight	99000 g
