Miele W 1714 User Manual

Temperature unit
You can chose for the temperature to
be displayed as °C/Celsius or
°F/Fahrenheit.
The machine is delivered with
°C/Celsius as the default setting.
Buzzer
When the buzzer function has been
activated, an audible tone sounds at
the end of a programme or when
Rinse hold is reached.
There are two volumes:
Normal
(the machine is delivered with this
option as the default setting.)
The buzzer sounds at the end of a
programme or when Rinse hold is
reached.
Loud
The buzzer sounds at maximum volume
Loud at the end of a programme or
when Rinse hold is reached.
Keypad tone
An audible tone sounds each time a
button is pressed.
The machine is delivered with the
keypad tone deactivated.
Brightness
There are ten different display
brightness settings.
The bar chart shows you the setting.
The machine is delivered with the
display brightness on setting 5.
This will change as soon as a different
setting is chosen.
Contrast
There are ten different display
contrast settings.
The bar chart shows you the setting.
The machine is delivered with the
display contrast on setting 5.
This will change as soon as a different
setting is chosen.
Programmable functions
58

Miele W 1714 Specifications

General

Current	10 A
Connected load	2300 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (typical)	2100 W
Water consumption per cycle	47 L
Energy consumption washing per cycle	1.02 kWh
Door color	Gray
Door hinge	-
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Drum capacity	6 kg
Cycle time (max)	109 min
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (wash)	- dB
Washing class	A
Annual water consumption washing	9400 L
Annual energy consumption washing	204 kWh

Weight and Dimensions

Depth	634 mm
Width	595 mm
Height	850 mm
Weight	99000 g
