Miele W 1714 User Manual

Washing
The figure quoted in the bucket is the
maximum temperature the garment
can be washed at. The number of
bars under the symbol indicates the
level of agitation permitted.
9 No bar under the symbol: =
normal agitation
4 One bar under the symbol: =
reduced agitation
c Two bars under the symbol: =
much reduced agitation
/ Hand wash (if no temperature
is specified use the lowest
temperature or cold)
h Do not wash
Drying
The number of dots indicates the
drying temperature
q Normal temperature
r Low temperature
s Do not tumble dry
Ironing
The number of dots indicates the
ironing temperature
I Hot iron (max sole plate temp.
approx. 200°C)
H Medium hot iron (max sole
plate temp. approx. 150°C)
G Cool iron (max sole plate
temp. approx. 110°C). Do not
steam iron garments carrying
this symbol.
J Do not iron
Professional cleaning
f Dry clean only. The letters
indicate the type of cleaning
agent required.
p
w Professional Wet Clean only
D Do not dry clean
Bleaching
x Any oxidising bleaching
agent can be used
{ Only use an oxygen based
bleach or a non-chlorine
bleach
z Do not bleach
Garment care label symbols
24

Miele W 1714 Specifications

General

Current	10 A
Connected load	2300 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (typical)	2100 W
Water consumption per cycle	47 L
Energy consumption washing per cycle	1.02 kWh
Door color	Gray
Door hinge	-
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Drum capacity	6 kg
Cycle time (max)	109 min
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (wash)	- dB
Washing class	A
Annual water consumption washing	9400 L
Annual energy consumption washing	204 kWh

Weight and Dimensions

Depth	634 mm
Width	595 mm
Height	850 mm
Weight	99000 g
