Miele W 1714 User Manual

With the help of the following notes, minor faults in the performance of the
machine, some of which may result from incorrect operation, can be put right
without contacting the Service Department.
,
Repair work to electrical appliances should only be carried out by a
suitably qualified person in strict accordance with current local and national
safety regulations. Repairs and other work by unqualified persons could be
dangerous. The manufacturer cannot be held liable for unauthorised work.
The programme does not start
Problem Possible cause Remedy
The display remains
dark, and the Start/
Stop button indicator
light does not come
on.
There is no power to
the machine.
Check whether
– the mains plug is plugged
in and switched on.
– the fuse or circuit breaker
has tripped.
You are asked to enter
a code.
Access via a code has
been activated.
Enter the code and confirm
the entry. Deactivate the code
if you do not wish this
message to appear in the
display the next time the
machine is switched on.
The display is dark. The display has
switched off
automatically to save
energy (Standby
mode).
Press a button. Standby
comes to an end.
Problem solving guide
33

Miele W 1714 Specifications

General

Current	10 A
Connected load	2300 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (typical)	2100 W
Water consumption per cycle	47 L
Energy consumption washing per cycle	1.02 kWh
Door color	Gray
Door hinge	-
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Drum capacity	6 kg
Cycle time (max)	109 min
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (wash)	- dB
Washing class	A
Annual water consumption washing	9400 L
Annual energy consumption washing	204 kWh

Weight and Dimensions

Depth	634 mm
Width	595 mm
Height	850 mm
Weight	99000 g
