Building under a continous worktop /
in a kitchen run
,
A building-under kit (available
to order) with a cover plate to
replace the machine lid is required.
It must be fitted by suitably qualified
person to ensure electrical safety.
N.B. If you wish to push your machine
under a worktop and there is space to
do this without removing the lid the
building under kit is not necessary.
Otherwise the building under kit is
essential.
The building-under kit is supplied with
its own installation instructions.
–
Slides are also available to order for
fitting underneath the machine feet to
protect the floor from damage when
the machine is pushed into position
or taken out for servicing.
–
Connections for electricity, water and
drainage should be installed in such
a way that they remain accessible
when the machine is in place.
N = Niche height (820-930 mm)
(illustration shows machine with lid removed)
Niche height Action
820 mm None required
from 830 -
840 mm
Fit longer screw feet*
(Set to approx.
40 mm)
from 870 -
885 mm
Use one raising kit*
from 915 -
930 mm
Use two raising kits*
* accessory available to order
If the kitchen run has a continuous
furniture plinth in place, a gap must
be made for the washing machine.
Replacing the lid
If the lid has been removed in order to
fit a coverplate, ensure that, if the lid is
ever replaced, it fits securely into the
rear holders. Otherwise, it is not
properly secure for transport.
Installation and connection
67
