Miele WT 2670 WPM User Manual

Fitting a plinth facing
The gap between the lower edge of the
machine plinth and the floor can be
closed up using a suitable kitchen
furniture plinth facing.
The washing machine plinth has a
special groove in which a plinth facing
can be fitted.
Plinth facing dimensions
Length
: 592 - 596 mm
Thickness
:8mm
Height (
H): The plinth facing height
must be calculated after aligning the
height of the machine with the screw
feet or after fitting the height-adjustment
frame(s).
Installation
^ Calculate height (H) from the floor up
into the groove (on the underside of
the washing machine).
^ Cut the plinth facing to size.
^ Slide it into the groove.
Useful tip:
If the machine is fitted on a
height-adjustment frame, you can use
double-sided adhesive tape on the
back of the plinth facing to secure it to
the height-adjustment frame too.
Installation and connection
70

Miele WT 2670 WPM Specifications

General

Door hinge	Left
Loading type	Front-load
Product color	White
Appliance placement	Freestanding
Washing capacity	5 kg
Delay start (max)	24 h
Maximum spin speed	400 RPM
Washing class	A
Water consumption per cycle	65 L
Energy consumption washing per cycle	3.4 kWh
Drum interior light	Yes

Weight and Dimensions

Depth	580 mm
Width	595 mm
Height	850 mm
