Shortening the door panel
You can shorten the door panel to
match the height of adjacent kitchen
unit door fronts.
First of all you need to calculate
measurement X. This is the distance
from the lower edge of the machine
door to the lower edge of an adjacent
kitchen unit door front.
Procedure
^
Open the door.
^ First remove the door panel:
– to do this unscrew the 10 screws
(see arrows) from the inside machine
door.
^ Then remove the three decor strips
from the door panel:
– to do this unscrew the screws.
^ Shorten the door panel
and the two
side decor strips
at the bottom by
measurement X using a suitable saw.
^
Drill four holes for securing the lower
decor strip into the door panel.
^
Fit the decor strips and the door
panel.
If you are intending to fit a decor
panel, check whether this will also
need to be shortened
Installation and connection
69

Miele WT 2670 WPM Specifications

General

Door hinge	Left
Loading type	Front-load
Product color	White
Appliance placement	Freestanding
Washing capacity	5 kg
Delay start (max)	24 h
Maximum spin speed	400 RPM
Washing class	A
Water consumption per cycle	65 L
Energy consumption washing per cycle	3.4 kWh
Drum interior light	Yes

Weight and Dimensions

Depth	580 mm
Width	595 mm
Height	850 mm
