1-3
USB port is to connect the printer and other external equipments; serial port is to
transmit the data after connected to PC.
1.2 Parameters
Light source Tungsten-halogen lamp (6V, 10W)
Filter
Interferential filter.6 wavelengths (available): 340nm,
405nm, 510nm, 546nm, 578nm and 630nm.2
wavelengths (optional): 450nm and 670nm.
Absorbance range
0～3.0A
Readable range
0～3.5A
Result resolution 0.001A
Reaction container
Flow colorimetric pool (32 ul）
Reaction temperature
25℃, 30℃, 37℃ and room temperature.
Result storage capacity No less than 3000 results.
Test storage capacity Up to 200 tests information,1000 control results
Weight 7kg
Dimension
420mm×350mm×158mm（length×width×height）
Power supply
100V-240V~ (±10% fluctuation) ， 50/60Hz (±3Hz
fluctuation)
Input power 140VA
1.3 Touchpen and Popup Keypad
The system is provided with a touchpen, which is used in combination with
touchscreen and popup keypad to operate the system.
CAUTION
Be sure to use the supplied pen to operate the touchscreen. Do not
touch the screen with sharp-edged tools. Otherwise the screen may be
damaged.
1.3.1 Touchpen
The system is provided with a touchscreen and pen, which are used as input tools
and can be operated as follows:
Click
’Click’ means the act of moving the pen to the desired item and then touching the
screen gently.
