4-16
The following table explains the parameters on the Test screen.
Parameter Description
Tests
A list of all the on-board tests. The requested test is marked with
“*”.
Parameter View parameters of the selected test.
Parameters include: test name, reaction type, wavelength,
temperature, delay, measuring time, aspiration volume, blank
mode, calibration equation (K factor). Click Return to return to
Test
System status
area
Instrument status and information during test is shown in this
area.
When system is normal, the area shows Standby
When sample or other solution to be tested is selected, the area
shows: Please aspirate.
When system fails, the area shows: error!
When temperature is not stabilized, the area shows:
Temperature stabilizing…
During test, the area shows: Testing…
When light intensity is too weak, the area shows: light source
too weak.
When saving the result, the area shows: Result saved.
Sample
information
The area shows the sample ID of the current sample. Use “+”
and “-“to change the sample ID. After the completion of a sample
test, the sample ID of the sample blank will increase by 1 (if
requesting is applied, increase the sample ID according to
requesting).
Click this button to wash the tubes after system aspirating
distilled water.
To Next Page
