Minelab GPX 6000 User Manual

8
CONTENTS
ML 100 Headphones Pairing Procedure
Pairing the ML 100 headphones is only required at first time use. They will automatically connect for all future uses.
Re-pairing is required following a Factory Reset of either the headphones or the detector.
When Bluetooth® headphones are paired, the Bluetooth® Indicator will indicate the type of headphones that are in use.
Standard Bluetooth® Bluetooth® Qualcomm® aptX™ Low Latency
START `
1. Make sure headphones are off, and
close to the detector.
Ensure the headphones are turned off and are no more than
1 metre (3.3 feet) away from the detector.
2. Turn on the headphones and
enter pairing mode.
Long press for at
least 7 s
Press and hold the Multi-Function button on the headphones
until two ascending tones are heard and the Status LED
alternates blue and red.
3. Enable Bluetooth® on the detector
and enter pairing mode.
Long press for at
least 2.5 s
Press and hold the Bluetooth® button on the side of the
GPX 6000™ control panel until the Bluetooth® indicator begins
to flash rapidly.
For first-time use of the detector or following a factory reset, a
short press of the Bluetooth® button will immediately initiate the
pairing sequence.
4. Headphones will
automatically connect.
If pairing is successful, the headphones will beep, and the
Bluetooth® and wireless headphones indicators will remain on.
The Status LED on the headphones will flash blue once every
3 seconds during use.
To Factory Reset the ML 100 headphones, press the Multi-Function button for more than 10 seconds. All previous pairings
and settings will be deleted.

Minelab GPX 6000 Specifications

General

Technology	GeoSense-PI
Weight	2.1 kg (4.6 lbs)
Battery Type	Rechargeable Lithium-ion
Battery Life	Up to 8 hours
Display	LCD
Warranty	3 years
Operating Frequency	Multi-frequency
Ground Balance	Automatic and Manual
Manufacturer	Minelab
Coil Options	11" Monoloop, 14" DD, 17" Monoloop
Audio Output	Built-in speaker
Headphones	Wireless headphones included
Water Resistance	Coil waterproof to 1 m (3 ft)

Summary

Getting Started

Quick Start Procedure

Step-by-step guide to quickly set up the detector for initial use.

Controls

Control Panel Overview

Identifies and describes the functions of each control button on the detector.

Display

Display Indicators

Explains the meaning of icons and readings shown on the detector's display screen.

Battery

Battery Charging

Instructions for charging the rechargeable lithium-ion battery using AC or DC chargers.

Bluetooth® Headphones

Headphone Features and Pairing

Details on ML 100 headphones, features, wired operation, and pairing procedure.

Coils

Coil Types and Changing

Describes GPX 6000 coils (Mono, Double-D) and the process for changing them.

Automatic Operation

Intelligent Automatic Operation

Guide to using the detector's automatic operation for optimal sensitivity and noise reduction.

Automatic Sensitivity

Auto and Auto+ Modes

Explanation of the two automatic sensitivity modes and their application in different conditions.

Manual Procedures

Manual Sensitivity Adjustment

Procedure for manually setting sensitivity to maximise target detection and minimize noise.

Noise Cancel

Noise Cancel Procedure

Steps to perform Noise Cancel to reduce erratic audio responses caused by EMI.

Double-D Coil Noise Cancel

Procedure for Noisy Ground

Specific procedure for noise cancellation when using a Double-D coil in noisy ground.

Ground Balance

Ground Balance Concepts

Explains automatic tracking, Quick-Trak, and Ground Type settings for managing ground noise.

Quick-Trak Procedure

Ground Balance Recalibration

Steps to manually recalibrate the detector to new ground conditions using Quick-Trak.

Ground Balance Procedures

Normal and Difficult Ground Balance

Procedures for balancing normal and difficult/variable ground conditions.

Conductive Ground Balance

Procedure for Salty Ground

Procedure for ground balancing in conductive (salty) ground conditions using a Double-D coil.

Advanced Concepts

Identifying Noise Sources

Explains how to identify the sources of detector noise like EMI and ground noise.

Ground Noise Types

Conductive Ground Noise

Details on identifying and managing noise caused by conductive (salty) soils.

Double-D Modes

Choosing Double-D Mode

Guide to selecting between EMI Cancel and Conductive Ground Cancel modes for Double-D coils.

Threshold Tone

Threshold Tone On/Off

Instructions on how to toggle the optional Threshold Tone on or off.

Troubleshooting

Errors and Coil Overload

Solutions for common errors, coil errors, system errors, and coil overload issues.

General Troubleshooting

Common Issues and Solutions

Addresses common problems like no sound, pairing issues, and slipping shafts.

Care and Safety

Safety Recommendations

Guidelines for operating and maintaining the detector safely and prolonging its lifespan.

Specifications
