This UPS does not include a Bypass input circuit breaker (MCCB) to protect
bypass circuit. The Bypass input circuit breaker (MCCB) is to be field
supplied and installed. Recommended Breaker (MCCB)'s Specifications are
as follows:
Table 1.2 Rating of Bypass Input Circuit Breaker
Capacity (kVA) Bypass Voltage (Vac) Bypass Rating (Aac) Breaker (A)
1050 480 1263 1600
1400 480 1684 2500
1750 480 2105 3000
2100 480 2526 4000
AC input and AC output overcurrent protection and disconnect devices shall be field
supplied and installed. The DC circuit breaker (MCCB) shall be field supplied and
installed. The overcurrent protection device should be installed in the Battery cabinet
and rated as indicated in Table 1.6.
