1.5 SPECIFICATIONS
The UPS nameplate displays the rated kVA as well as nominal voltages and currents. The
nameplate is located on the backside of the Bypass Module door.
Table 1.3 Power Specifications
Rated output
Power
Input voltage
3 phase / 3 wire
Bypass input voltage
3 phase / 3 wire
Output voltage
3 phase / 3 wire
1050kVA / 1000kW 480V 480V 480V
1400kVA / 1330kW 480V 480V 480V
1750kVA / 1660kW 480V 480V 480V
2100kVA / 2000kW 480V 480V 480V
Table 1.4 UPS Cabinet Information
UPS
[kVA]
Cable
Entry
Width
[in / mm]
Depth
[in / mm]
Height
[in / mm]
Weight
[lb./ kg]
Heat Loss
[kBTU / h]
1050 BOTTOM / TOP 118.2 / 3003.2 35.5 / 901.6 80.7 / 2048.6 6283 / 2850 127.6
1400 BOTTOM / TOP 167.3 / 4250 35.5 / 901.6 80.7 / 2048.6 9580 / 4350 159.7
1750 BOTTOM / TOP 198.8 / 5050 35.5 / 901.6 80.7 / 2048.6 11770/ 5350 199.7
2100 BOTTOM / TOP 222.4 / 5650 35.5 / 901.6 80.7 / 2048.6 13530 / 6150 239.6
