MITSUBISHI ELECTRIC 9900CX SERIES UPS

9900CX SERIES UPS

OWNERS / TECHNICAL MANUAL

Page Number:

2-1

C

2.0 OPERATOR CONTROLS AND INDICATORS

The 9900CX Series operator controls and indicators are located as follows (Bypass Module door

exterior) :

Figure 2.1

Operation/Display Panel (Front panel)

8

3

2

1

7

4

5

6
