3 Controller
Outside dimensions/Installation dimensions 3-56
3.3.3 Cable lead-in and dimension
The controller has the openings parts for pulling out the cable as shown in Fig. 3-15 and Fig. 3-16.
Fig.3-15 ： Cable lead-in and dimension of the controller （CR2DA-700 series）
<CR2DA-700 series>
27
18.7 23.8
配線固定具
Input power supply lead-in
Cable fixing plate
