Mitsubishi Electric PAR-32MAA Instruction Book

34
Setting the temperature range restriction
Controller operation-Function settings
Restriction
1
F1 F2 F3 F4
Main
Main display:
Cursor Page
Main menu
Restriction
Energy saving
Night setback
Filter information
Error information
Select "Restriction" from the Main menu (refer to
page 20), and press the SELECT button.
2
F1 F2 F3 F4
Restriction
Setting display:
Page
Temp. range Yes
Cool·Dry
Heat
Auto
-
-
-
The current settings will appear.
Move the cursor to "Temp. range" with the F1 or
F2 button, and press the SELECT button.
3
F1 F2 F3 F4
Temp. range
Select:
Cursor Cursor
Temp. range No / Yes
Cool·Dry
Heat
Auto
-
-
-
The screen to set the temperature range will
appear.
Move the cursor to the desired item with the F1
button out of "Temp. range," "Cool•Dry," "Heat,"
or "Auto."
P
Button operation

Mitsubishi Electric PAR-32MAA Specifications

General

Brand	Mitsubishi Electric
Model	PAR-32MAA
Category	Remote Control
Language	English
