45
Controller operation-Function settings
Manual vane angle
1
F1 F2 F3 F4
Main
Main display:
Cursor Page
Main menu
Maintenance
Initial setting
Service
Select "Maintenance" from the Main menu (refer
to page 20), and press the SELECT button.
3
F1 F2 F3 F4
Manual vane angle
Input display:
Cur. Address Check
Ref. address
Unit No.
Identify unit Check button
Move the cursor to "Ref. address" or "Unit No."
with the F1 button to select.
Select the refrigerant address and the unit
number for the units to whose vanes are to be
fixed, with the F2 or F3 button, and press the
SELECT button.
•
Ref. address: Refrigerant address
•
Unit No.: 1, 2, 3, 4
Press the F4 button to confirm the unit.
2
F1 F2 F3 F4
Maintenance menu
Main menu:
Cursor
Auto descending panel
Manual vane angle
3D i-See sensor
Select "Manual vane angle" with the F1 or F2
button, and press the SELECT button.
OFF
The screen at left shows a sample display on Mr. Slim. On
City Multi units, "M-NET address," is displayed instead of
"Ref. address", and the "Unit No." will not be displayed.
Main
Button operation
To Next Page
