9
Mode # Indoor Unit Compatibility Function Setting # Settings
16 SVZ/PVA Humidifier Control
1 With compressor only
2 In Heat mode all the time
17
PLA
PCA/PKA
Change of Defrosting Control
1 Standard
2 High humidity
23
*D
PLA-BA Vane Swing
1 Swing
2 Wave air flow
23
*D
PCA/PKA Vane Swing
1 Not available (OFF)
2 Available (ON)
23
*D
SLZ
SEZ
Heater Control *23-1
1 Set temp -4.5 °F ON
2 Set temp -1.8 °F ON
23
*D
SVZ/PEAD/PVA Heater Control *23-1
1 Disable heater during Defrost/Error
2 Enable heater during defrost and error *23-2
24
SLZ/PLA
SEZ/SVZ/PEAD
PCA/PKA *24-1
Heating Height Offset 4
1 Available (ON) 4 °C (7.2 °F) up
2 Not available (OFF)
25
SLZ/PLA
SEZ/SVZ/PEAD/PVA
PCA/PKA
Fan Speed Thermo-Off Heating
1 Extra low
2 Stop
3 RC setting
26
*D
SLZ-KF/PLA-A__EA7
3D i-See Sensor Height Offset Setting
*12-1 *12-2
1 Low (less than 8.9 feet)
2 Standard (8.9 to 11.5)
3 High (11.5 to 14.8)
26
*D
SVZ Erv Control
1 IDU STOP, fan speed STOP, and CN2C is OFF
2 IDU STOP, fan speed is RC Setting, and CN2C is ON
27
SLZ/PLA
SEZ/SVZ/PEAD
PCA/PKA
Fan Speed Thermo-Off Cooling
1 RC setting
2 Stop
3 Extra Low *27-1
28
SLZ/PLA
SEZ/SVZ/PEAD
PCA/PKA
Detection of Abnormal of the Pipe
Temperature (P8)
1 Available (ON)
2 Not Available (OFF)
M-Series & P-Series Indoor Unit Function Codes
Notes:
*D Duplicate code with multiple settings for different indoor unit types.
*1-1 When the power supply returns, the air conditioner will start 3 minutes or 1 minute later (hinge on outdoor unit).
*2-1 Can be set only when a wired or RedLINK Remote Controller is used.
*11 Because condensation may form, do not use this setting in a high-temperature, high-humidity environment.
*12-1 Cassette must have 3D i-See Sensor installed to operate, refer to install manual.
*12-2 When the 3D i-See Sensor corner panel position is changed, change this mode.
*23-1 For the detail of heater control, refer to the service manual.
*23-2 Heater will only operate during a communication error between indoor unit and outdoor unit.
*24-1 PKA-HA(L)/KA(L): 3.6°F (2°C) up.
*27-1 Only SLZ and PLA are able to set this setting.
33-00446EFS_B.indd 9 10/17/2019 3:09:00 PM
