8.2 Outdoor unit
8.2.1 SRC20MA-S
SRC20MA-S-PANEL&FAN ASSY
NO.
Parts No
Parts Name
RE.Q
1
RYF122A002
PANEL ASSY,FRONT
1
2
RYF124A001A
PANEL,TOP
1
3
RYF123A002
PANEL,SIDE(R)
1
4
RYF435A003A
GRILL ASSY,AIR OUT
1
5
RYF132A002
PANEL ASSY,SERVICE
1
6
RYF944B001
HANDLE
1
7
RYF142A013
COVER(TB)
1
8
RYF913A002
SCREW,TAP
12
9
RYF913A002A
SCREW,TAP
5
10
W010D04X008
TAP-SCREW,CRS-TRS 1
6
11
W010D04X012
TAP-SCREW,CRS-TRS 1
2
12
RYF129A006
PLATE
1
13
RYF937A002A
CLAMP,WIRE
1
14-18
RYF401A011G
FAN EQUIP ASSY
1
14
RYF116A006
BRACKET ASSY，MOTOR
1
15
RYF512T010
MOTOR,DC
1
16
RYF431B502
PROPELLER
1
17
SSA914B007AC
NUT,TH
1
