8 MOUNT ASSEMBLY
8.1 Indoor unit
8.1.1 SRK20MA-S
SRK20MA-S-PANEL&FAN ASSY
NO.
Parts No
Parts Name
RE.Q
1-7
RYD102A033H
PANEL ASSY,FRONT
1
1
RYD122A057C
PANEL,FRONT
1
2
RYD435A056G
GRILLE,AIR INLET
1
3
RYD437A030
FILTER,AIR
2
4
RYD129A088A
CAP
2
5
RYD133A049
PLATE ASSY,ORNAMENT
1
6
RYD129A047
HOLDER,FILTER
2
7
RYD011F037
LABEL,MODEL NAME
1
8-26
RYD435A054A
GRILLE ASSY,AIR OUT
1
8
RYD435A055
GRILLE,AIR OUTLET
1
9
RYD436A033A
FLAP(A)
1
10
RYD436A034A
FLAP(B)
1
11-12
RYD436A035
LOUVER ASSY(R)
1
11
RYD436A037
LOUVER
5
12
RYD129A096
PLATE,CONNECTING(R)
1
13-14
RYD436A036
LOUVER ASSY(L)
1
13
RYD436A037
LOUVER
5
14
RYD129A097
PLATE,CONNECTING(L)
1
