131
-
(3) Operation chart
The Multi-Type V series is a system that allows for different models and capacities of indoor units to be connected so the individual
operating characteristics of the indoor and outdoor are provided. Use the procedure shown in Item (c) to calculate the combined
operating characteristics.
(a) Operating characteristic of outdoor unit
Cooling power consumption
Heating power consumption
Cooling running current
Heating running current
Inrush current (L.R.A)
(220/240 V)
Item
Model
FDCVA302HENR
2.02
2.16
10.4
11.1
5
kW
A
A
(b) Operating characteristic of indoor unit
Notes(1) This packaged air-conditioner is manufactured and tested in conformity with the following standard.
ISO-T1 “UNITARY AIR-CONDITIONERS”
(2) The values shown in the above table are common to both cooling and heating operations.
FDT 151R
FDTC 151R
FDEN 151R
FDKN 151R
Cooling power consumption
Heating power consumption
Cooling running current
Heating running current
(220/240 V)
Item
Model
FDTCA151R
0.046/0.046
0.046/0.046
0.15/0.14
0.15/0.14
kW
A
Cooling power consumption
Heating power consumption
Cooling running current
Heating running current
(220/240 V)
Item
Model
FDTA151R
0.046/0.075
0.061/0.071
0.32/0.34
0.30/0.33
kW
A
Cooling power consumption
Heating power consumption
Cooling running current
Heating running current
(220/240 V)
Item
Model
FDENA151R
0.054/0.061
0.050/0.056
0.25/0.26
0.23/0.24
kW
A
Cooling power consumption
Heating power consumption
Cooling running current
Heating running current
(220/240 V)
Item
Model
FDKNA151R
0.02/0.02
0.02/0.02
0.2/0.2
0.2/0.2
kW
A
