Mitsubishi FDCVA302HENR User Manual

-
7
-
Model FDUMVA302HEN2R
Item
Model
FDUMA302R FDCVA302HENR
Nominal cooling capacity
(1)
kW 7.1[3.5~8.0]
Nominal heating capacity
(1)
kW 8.0[4.0~9.0]
Power source 1 Phase, 220/230/240V, 50Hz
Cooling power consumption kW 2.08
Running current (Cooling) A 9.2
Power factor (Cooling) % 98
Heating power consumption kW 2.21
Running current (Heating) A 10.2
Power factor (Heating) % 94
Inrush current (L.R.A) A 5
Noise level dB(A) Hi:35 Me:32 Lo:29
Exterior dimensions
mm 299 × 950 × 635 750× 880 (+88)× 340
Height × Width × Depth
Net weight kg 40 60
Refrigerant equipment
–
2YC45DXD × 1
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 2.95 [Pre-charged up to the piping length of 30m]
Refrigerant oil r – 0.48 (BR68A)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty
Multiblade centrifugal fan × 2 Propeller fan × 1
Motor W 100 × 1 120 × 1
Starting method Direct line start
Air flow CMM Hi: 20 Me:18 Lo:15 Cooling:60 Heating:48.5
Available static pressure
Pa Standard: 50, Max: 85 –
Outside air intake – –
Air filter, Q’ty – –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20(Crank case heater)
Operation control Wired remote control switch (Optional: RC-E1R)
Operation switch Wireless kit (Optional: RCND-KIT-HER)
– (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Abnormal discharge temperature protection.
Installation data mm
Liquid line: φ9.52 (3/8″) Gas line: φ15.88 (5/8″)
Refrigerant piping size (in)
Connecting method Flare piping
Drain hose Connectable with VP25 (I.D.25mm, O.D.32mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts Filter kit (UM-FL2E)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard.
ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 230V 50Hz.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
Operation data
(3)
FDUMVA302HEN2R
48
(3) Satellite ducted type (FDUM)
