14
-
(3) Outdoor unit
Model FDCVA302HENR
Unit: mm
Terminal block
Gas piping ø15.88 (5/8")
Liquid piping ø9.52(3/8")
(Flare connecting)
(Flare connecting)
25.1165.5
30
°
30°
48.5103.3
750
24.1
Holes for drain
2-ø15
25.8
29.8
87.9
880
150580150
61
532
223
60
15
340
61 47.5
19 380 19
418
Required space for maintenance and air flow Minimum allowable space to the obstacles
Unit:mm
Mark
123
L1 Open Open
500
L2 300 250 Open
L3 100 150
100
L4 250 250 250
Installation
type
Notes
(1) It is prohibited to install in a space enclosed with walls
at four sides.
(2) Unit must be secured with anchor bolts.
Anchor bolt should not protrude more than 15 mm above
the surface.
(3) Where strong winds blow,the blow outlet must be
oriented at right angle against the wind direction.
(4) Secure a space of 1 m or more above the unit.
(5) Barrier standing in front of the blow outlet mustbe lower
than the height of unit.
L2
L1
L3
L4
Air inlet
Air outlet
Maintenance
space
( )
Air
inlet
(ø20×3 pcs.)
