FX1N Series Programmable Controllers Installation Notes 3.
3-10
3.5 DIN Rail Mounting
Units can be snap mounted to 35mm (1.37") DIN rail (DIN EN 50022). To release, pull the
spring loaded clips away from the rail and slide the unit up and off.
3.6 Direct Mounting
∅
= 4.5mm (0.17")
Table 3.3 :Hole positions
UNIT
mm inches
± 0.2 ± 0.01
A = W-8mm (0.32")
FX
1N
-14M
✩
2-
∅
(
→
)
82 3.23
FX
1N
-24M
✩
82 3.23
FX
1N
-40M
✩
122 4.81
FX
1N
-60M
✩
167 6.58
B = W-10mm (0.40")
FX
0N
-40E
✩
2-
∅
(
→
)
140 5.52
FX
2N
-32E
✩
140 5.52
FX
2N
-48E
✩
4-
∅
(
→
)
172 6.78
FX
2N
-48ER-UA1/UL 210 8.27
N
X14
24V
Y7
Y6
Y0
FX
1N
-24MR
X0 X2
X1
X3 X5
X4
X7
X6
X11
X10
S/S
X13
X12
X15
L
0V
Y11
COM2
COM4
Y10Y5
Y4
Y2
Y1
COM0 COM1
COM3
Y3
POWER
ERROR
IN
OUT
0123
0123
RUN
4567
4567
1110
131110 12
14 15
W
A
82 (3.20'') 90 (3.54'')
75 (2.95'')
8 (0.31'')
DIN rail
mounting
slot
2 - φ4.5 (0.17'')
2 - φ4.5 (0.17'')
W
B
80 (3.15'')
90 (3.54'')
87 (3.43'')
9 (0.36'')
DIN rail
mounting
slot
