Mitsubishi FX1N-40MR-DS User Manual

FX1N Series Programmable Controllers Power Supply 4.
4-2
4.3 Power Supply
• When wiring an AC supply, the “Live” cable should be connected to the “L” terminal and the
“Neutral” cable should be connected to the “N” terminal. Do NOT connect the “Live” wire to
the “N” terminal, otherwise, the user may receive a dangerous shock upon powerup.
• When wiring a DC supply the “Live” cable should be connected to the “+” terminal and the
“Neutral” cable should be connected to the “-” terminal. Do NOT connect the “Live” wire to
the “-” terminal, otherwise, the user may receive a dangerous shock upon powerup.

Mitsubishi FX1N-40MR-DS Specifications

General

Brand	Mitsubishi
Model	FX1N-40MR-DS
Category	Controller
Language	English
