4. Power Supply
4.1 Wiring Techniques
Wiring for FX
1N
products has been designed to be safe and easy. If the user is concerned
about the correct installation of these products or associated products, please contact a
professional electrician who is trained to the local and national standards applicable to the
installation site.
4.2 Wiring Cautions
• Do not run input signals in the same multicore cable as output signals or allow them to
share the same wire.
• Do not lay I/O signal cables next to power cables or allow them to share the same trunking
duct. Low voltage cables should be reliably separated or insulated with regard to high
voltage cabling.
• Where I/O signal lines are used over an extended distance consideration for voltage drop
and noise interference should be made.
FX1N Series Programmable Controllers
