MELSEC-Q
APPENDIX
Appendix 6 EDS File of the QJ71DN91
The following shows the EDS file of the QJ71DN91. The EDS file is stored in the CD-
ROM of GX Configurator-DN.
$ Mitsubishi Master/Slave EDS file
$ File Description Section
[File]
DescText="QJ71DN91 EDS file";
CreateDate=08-28-2000; $ created
CreateTime=12:00:00;
ModDate=08-28-2000; $ last change
ModTime=12:00:00;
Revision=1.1; $ Revision of EDS
$ Device Description Section
[Device]
VendCode=0xA1;
VendName="MITSUBISHI ELECTRIC CORPORATION";
ProdType=0x0C; $ Communication Adapter Device
ProdTypeStr="Communication Adapter"; $ Communication Adapter Device
ProdCode=4;
MajRev=1;
MinRev=1;
ProdName="QJ71DN91";
Catalog="";
$ I/O Characteristics Section
[IO_Info]
Default=0x0001; $ Poll Only
PollInfo=0x0001,
1, $ Default Input = Input1
1; $ Default Output = Output1
$ Input Connections
Input1= $Input(Producing)
8, $ 8 byte
0, $ 0 bits are significant
0x0001, $ Poll Only Connection
"Input Data", $ Name
6, $ Path Size
"20 04 24 64 30 03", $ Assembly Object Instance 100
"Data"; $ Help
$ Output Connections
Output1= $Output(Consuming)
8, $ 8 byte
0, $ 0 bits are significant
0x0001, $ Poll Only Connection
"Output Data", $ Name
6, $ Path Size
"20 04 24 65 30 03", $ Assembly Object Instance 101
"Data"; $ Help
[ParamClass]
MaxInst=0;
Descriptor=0x00;
CfgAssembly=0;
