4 - 1 4 - 1

MELSEC-Q

4 SETUP AND PROCEDURES BEFORE OPERATION

This chapter describes the procedures up to system startup using the QJ71DN91.

4.1 Setup and Procedures before Operation

4.1.1 When using the master function

Start

Perform a hardware test (mode 9).

Set to mode 0 to 2.

Use

GX Configurator-DN?

Set "auto communication start

settings" using GX Configurator-DN

and load it to the QJ71DN91.

Create "parameters for the master

function" using GX Configurator-DN.

Set "auto refresh" using GX

Configurator-DN and load it to the

QCPU.

Create a sequence program for

control.

Load the sequence program to the

PLC CPU and reset.

Trial run?

Yes No

Create "parameters for the

master function" using a

sequence program.

Create "parameters for the

master function" using auto

configuration. ( )

Create a sequence program for "auto communication start

settings" and save it in the flash ROM of the QJ71DN91.

Create a sequence program

for refresh.

Create a sequence program

for control.

Load the sequence program to the

PLC CPU and reset.

Trial run?

End

Save the parameters using a

sequence program (Y17).

It is necessary to install a DeviceNet network and turn ON the power in advance.

Setting the

presence of auto

communication

Creating the

parameters for the

master function

Setting refresh
