SSDC-ECX-H/J Hardware Manual
400-820-9661
3.2 Digital Outputs
SSDC-ECX-H//J series drive has several digital optically isolated outputs, the function of every output
can be configurated by Stepper Suite software.
SSDC06/10-ECX-H
Signal Pin No. Function
Y2
5
Available function
：
Release brake output
Static in position output
Dynamic in position output
General purpose output
6
SSDC06/10-ECX-J
Signal Pin No. Function
Y1 10
Available function
：
Alarm output
Static in position output
Dynamic in position output
Y2 11
Available function
：
Release brake output
Static in position output
Dynamic in position output
YCOM 12 The common voltage of Y1/Y2
Y1、Y2: Optically isolated, 5-24VDC, Maximum pulse frequency = 10KHz.
The chats below show how to connect to the output:
(NOTE: Do not connect the outputs to more than 30VDC power supply.
And the current of each output terminal must not exceed 100mA.)
