Section 2 - General Information and Component Identification
Page 6 90-8M0082949 eng JULY 2013
Component Identification
a - Head
b - Curly cable
c - Stow/deploy release lever
d - Battery cables (hidden)
e - Wireless foot pedal
f - Handheld wireless remote
g - Deck mount
h - Propeller
i - Skeg
j - Lower unit (motor)
k - Depth collar
l - Depth collar knob
m - Composite column
n - Steering transmission
Recording the Serial Number
It is important to record the serial number and model number for future reference. The serial number tags are located on the
trolling motor as shown. Record the serial number and the model number in the space provided in the Warranty Information
section of this manual.
a - Model identification number
b - Serial number
