Section 6 - Owner Service Assistance
90-8M0082949 eng JULY 2013 Page 33
1. Remove the four screws from the back of the handheld remote. Remove the back cover.
a - Screws (4)
2. Remove the old battery from the battery holder.
3. Insert the new battery with the positive (+) side facing the positive (+) end of the battery holder.
4. Replace the handheld remote back plate and install the four screws. Ensure that the rubber seal is positioned correctly
between the two halves of the handheld remote. Tighten the screws securely.
a - Negative (–) end of battery holder
b - Battery
c - Positive (+) end of battery holder
d - Rubber seal
Service Assistance
Your satisfaction with your product is very important to us. If you have a problem or question about your motor, contact your
dealer or any certified MotorGuide Service Center. For more service assistance information, refer to Section 1 ‑ Warranty
Information.
