Line Status
Motorola, Inc. 570510-001-00 rev A Page 47 of 50
Line Current
This value indicated the total power consumed by the port; including power loss in the wire, in
the WallPlate, and efficiency.
Maximum power for any single line: 9 watts
Maximum line power for a complete system: 200 watts
To determine the power for a single line use the following chart:
Line Current Value Watts Reference
255 2.58 Idle, no load or wire attached
197 4.87
195 4.91
190 5.02
185 5.13
180 5.31
175 5.38
170 5.49
165 5.60
162 5.71
160 5.82
155 5.93
150 6.11
145 6.25
140 6.40
135 6.58
130 6.80
125 7.02
120 7.24
115 7.45
113 7.53
112 7.64
110 7.71
105 7.93
100 8.18
95 8.47
90 8.76
85 9.13 Maximum Power supported for the line
80 9.45
75 9.85
70 10.29
65 10.76
60 11.27
55 11.78
50 12.36
45 13.05
40 13.64
35 14.40
30 15.53
25 16.33
20 17.49
Out of spec
