Motorola GP328 Detailed Service Manual

6E-22 Circuit Board/Schematic Diagrams and Parts List
Lowband 29-42/35-50MHz Radio Parts
List
Circuit
Ref
Motorola
Part No.
Description
C103 2113740L25 20pF
C103** 2113740L24 18pF
C106 2113740L37 62pF
C106** 2113740L35 51pF
C107 2113740L39 75pF
C107** 2113740L36 56pF
C108 2113743F16 1.0uF
C110 2113740L34 47pF
C110** 2113740L33 43pF
C111 2113740L40 82pF
C111** 2113740L38 68pF
C114 2113740L39 75pF
C114** 2113740L37 62pF
C115 2113740L25 20pF
C115** 2113740L24 18pF
C118 2113740F48 47pF
C118** 2113740F49 82pF
C119 2113740F46 62pF
C119 2113740F39 33pF
C120 2113740F58 200pF
C121 2113740F58 200pF
C121** 2113740F59 220pF
C122 2113740A72 510pF
C123 2113740A72 510pF
C124 2113741A45 56pF
C125 2113743M24 0.01uF
C126 2113741A45 56pF
C127 2311049A18 10uF
C128 2113743M24 0.01uF
C129 2113743L41 0.01uF
C130 2113743L17 1000pF
C131‘ 2113743L17 1000pF
C132 2113743L41 0.01uF
C133 2113743M24 0.01uF
C134 2113743L41 0.01uF
C135 2113743L41 0.01uF
C136 2113743L41 0.01uF
C137 2113743L17 1000pF
C138 2113743L17 1000pF
C139 2113743L41 0.01uF
C140 2113743L41 0.01uF
C141 2113743L29 3300pF
C142 2113743L41 0.01uF
C143 2113743L41 0.01uF
C144 2113743L41 0.01uF
C145 2113741A45 56pF
C146 2113741A45 56pF
C147 2113743N34 22pF
C148 2113740F38 30pF
C149 2113743L41 0.01uF
C201 2113743L17 1000pF
C202 2113743N42 47pF
C203 2113743N34 18pF
C204 2113743L41 0.01uF
C205 2113743L41 0.01uF
C206 2113743N42 47pF
C214 2113741F49 0.1uF
C215 2113740L40 82pF
C216 2113740F38 30pF
C218 2113741F49 0.1uF
C219 2113741F49 0.1uF
C220 2113743N22 15pF
C221 2113741F49 0.1uF
C222 2113741F49 0.1uF
C223 2113743N19 5.1pF
C224 2113743N09 2pF
C225 2113743L41 0.1uF
C226 2113743N31 16pF
C227 2113741F49 0.1uF
C228 2113743N26 10pF
C229 2113743N48 82pF
C230 2113743N39 36pF
C231 2113743N44 56pF
C232 2113743A27 0.47uF
C233 2113743L41 0.01uF
C234 2113743A27 0.47uF
C235 2113932N44 56pF
C236 2113743N50 100pF
C237 2113743N12 2.7pF
C242 2113743N42 47pF
C247 2311049A56 4.7uF
C249 2113743L41 0.01uF
C255 2113741A61 0.047uF
C256 2113741A61 0.047uF
C257 2113741A61 0.047uF
C258 2311049F16 2.2uF
C259 2113743A27 0.47uF
C260 2113743F49 0.01uF
C261 2113741A27 0.47uF
C263 2311049A56 4.7uF
C280 2311049A57 10uF
C281 2104993J02 2.2uF
C283 2113743L41 0.01uF
C284 2113743L41 0.01uF
C285 2113743L41 0.01uF
C286 2113743L41 0.01uF
C287 2113743L41 0.01uF
C297 2113741F49 0.1uF
C298 2113743L41 0.01uF
Circuit
Ref
Motorola
Part No.
Description
C299 2311049A56 4.7uF
C301 2113743N30 15pF
C302 Not Placed
C303 2113743R33 4700pF
C304 2113743R33 4700pF
C305 2113743R33 4700pF
C306 2113743N65 8pF
C307 2113743E20 0.1uF
C308 2180478Z20 1uF
C309 2113741F49 0.1uF
C310 2113743E20 0.1uF
C311 2113743N29 13pF
C312 2113743N29 13pF
C313 2113743N29 13pF
C314 2113743N29 13pF
C315 2113743N25 9.1pF
C316 2113743N30 15pF
C317 2311049A59 10uF
C319 2311049A59 10uF
C320 2113743A23 0.22uF
C321 2113743E07 0.022uF
C323 2113743E07 0.022uF
C324 2113743N50 100pF
C325 2113743A23 0.22uF
C326 2113743E20 0.1uF
C327 2113743R33 4700pF
C328 2113743E07 0.022uF
C330 2113743E20 0.1uF
C331 2113743E07 0.022uF
C332 2113743E20 0.1uF
C333 2109720D14 0.1uF
C334 2113740A82 1500pF
C335 2113743A23 0.22uF
C336 2311049A59 10uF
C337 2113743E07 0.022uF
C339 2113743F16 1uF
C340 2113743F16 1uF
C341 2113743F16 1uF
C342 2113743F16 1uF
C343 2113743A23 0.22uF
C348 2113743N09 2pF
C400 2113743L41 .01uF
C401 2113743M24 0.1uF
C402 2113743M24 0.1uF
C403 2113743G24 2.2uF
C404 Not Placed
C405 Not Placed
C406 Not Placed
C407 2113928N01 0.1uF
C408 2113743N50 100pF
C409 2113743M24 0.1uF
Circuit
Ref
Motorola
Part No.
Description
C410 2113928N01 0.1uF
C411 2113743M24 0.1uF
C412 2311049A59 10uF
C414 2113743M24 0.1uF
C415 2109720D01 0.1uF
C416 2113928N01 0.1uF
C419 Not Placed
C420 2113743L41 .01uF
C421 2113928N01 0.1uF
C422 2113743M24 0.1uF
C423 2113743N50 100pF
C424 2311049A59 10uF
C425 2113743M24 0.1uF
C426 2113743N50 100pF
C427 2113743N50 100pF
C428 2113743M24 0.1uF
C429 2113743M24 0.1uF
C430 2113928N01 0.1uF
C431 2113743N50 100pF
C432 Not Placed
C433 2113743L41 .01uF
C434 2113743M24 0.1uF
C435 2113743M24 0.1uF
C436 2113743N34 22pF
C437 2113743N34 22pF
C438 2113743F18 2.2pF
C440 2113743F18 2.2pF
C441 2113743N50 100pF
C442 2113743E20 0.1uF
C443 2113928N01 0.1uF
C444 2113743N50 100pF
C445 2113743N50 100pF
C447 2113743M08 0.022uF
C448 2113928N01 0.1uF
C449 2113743N50 100pF
C450 Not Placed
C451 2113743M08 0.022uF
C452 2113743G26 4.7uF
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF
C471 2113743N50 100pF
C472 2113743N50 100pF
C473 2113743N50 100pF
C475 2113743H14 10uF
C476 2113928D08 10uF
C479 2113928N01 0.1uF
Circuit
Ref
Motorola
Part No.
Description
