8 Getting started
Charging the handset
3. If you are charging the battery for the rst time, place the handset on the base to
charge for at least 24 hours continuously.
4. When the handset is fully charged,
icon will appear steady on the display. Plug the
other end of the telephone line cord (make sure that one end is already plugged into
the base) into the telephone wall socket.
NOTE
You cannot access the battery in the handset. Do not attempt to remove the battery, as
you may damage the phone. If you need to replace the battery, contact the customer
service helpline found in this user guide.
Connecting the handset and charger
(for multi-pack only)
If you have purchased a multiple pack, you will need to carry out this process for all the
handsets and chargers.
1. Plug the power adapter into the socket marked
on the rear of the charger and plug
the other end into an electrical outlet.
2. If you are charging the battery for the rst time, place the handset on the charger to
charge for at least 24 hours continuously.
3. When the handset is fully charged,
icon will appear steady on the display. The
display will show
Handset
and handset number (e.g. 2) to indicate that it is registered
to the base.
BATTERY LOW WARNING
If you hear a warning beep every 2 minutes during a call, you will need to recharge the
handset before you can use it again.
When charging,
icon will scroll on the display.
BATTERY PERFORMANCE
In ideal conditions, fully charged batteries should give up to 7 hours talk time or up to 130
hours standby time on a single charge.
