Motorola MBP483 User Manual

Using the Baby Monitor 15
ENGLISH
3.4 Night Vision Mode
The Baby Unit has 6 high-intensity infrared LEDs for picking up clear images in
the dark. When the built-in photo sensor on the top of the unit detects a low level
of ambient light, the LEDs will automatically activate and the screen on the
Parent Unit will display in black and white. The
icon will be displayed at the
top of the screen.
3.5 Turn off Parent Unit LCD Screen
You can turn off the Parent Unit screen without switching off the Parent Unit.
When the screen is turned off, you can still hear sound from the Baby Unit.
Press the POWER ON/OFF button
on the Parent Unit to turn off the LCD
screen, but still leave the audio monitor on.
Press any key on the Parent Unit to turn on the screen again.

Motorola MBP483 Specifications

General

Type	-
Maximum range	- m
Volume control	Buttons
Frequency range	2407.5 - 2475 MHz
Channels quantity	21 channels
Number of brightness levels	5
Display type	LCD
Product color	Silver
Operating temperature (T-T)	5 - 45 °C
Battery voltage	3.6 V
AC input voltage	100-240 V
Battery capacity	800 mAh
Power consumption	1000 mA
Power source type	AC, Battery
AC input frequency	50 - 60 Hz
Battery technology	Nickel-Metal Hydride (NiMH)
Receiver power source	Battery
Transmitter power source	AC
LED type	IR
Sensor type	CMOS
Fixed aperture	2.6 mm
Fixed focal length	2.7 mm
Camera resolution (numeric)	0.3 MP
Number of illumination LEDs	6
Display diagonal	2.8 \
Frequency band	2.407 - 2.475 GHz
