Preparing Your Radio for Use
English
4
Attaching the Belt Clip
Align the grooves on the clip
with those on the battery and
press downwards until you
hear a click.
To remove the clip, press the
belt clip tab away from the
battery using a key. Then
slide the clip upwards and
away from the radio.
Attaching the Universal Connector Cover
(Dust Cover)
The universal connector is located on the antenna side of the
radio. It is used to connect MOTOTRBO accessories to the
radio.
Insert the slanted end of the
cover into the slots above
the universal connector.
Press downwards on the
cover to seat the dust cover
properly on the Universal
Connector.
Secure the dust cover to
the radio by pushing the
latch upwards.
To remove the dust cover,
push the latch downwards.
Lift the cover up and slide
down the dust cover from
the universal connector to
remove it.
Replace the dust cover
when the universal
connector is not in use.
3
1
2
NDP_ANZ-EMEA.book Page 4 Thursday, July 19, 2012 8:22 AM

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Motorola MOTOTRBO DP2400 and is the answer not in the manual?

Motorola MOTOTRBO DP2400 Specifications

General IconGeneral
Channel Capacity16 channels
Power OutputVHF: 1-5W, UHF: 1-4W
IP RatingIP55
Digital ProtocolDMR
Operating Temperature-30°C to +60°C
Programmable Buttons2
Frequency RangeVHF: 136-174 MHz, UHF: 403-470 MHz
