Motorola StarTAC 3000 Service Manual

© 1998 Motorola, Inc. 7
MANUAL TEST MODE
StarTAC 3000
Cellular Subscriber Group
Manual Test Mode
Introduction
Manual Test Mode software allows service
personnel to monitor the telephone status
on the display, and manually control tele-
phone functions via the keypad.
Manual Test Mode operates at two levels:
1. Status Display level, which allows the
phone to operate normally while
providing status indications in the
display.
2. Servicing Level, which disables normal
call-processing and allows commands to
be entered through the keypad to manu-
ally control operation of the phone.
Status Display
The Status Display information is described
in Figure 2: “Status Display Indicator” on
page 8 and the “02# Radio Status Request”
section of Table 3, “Test Commands For
Manual Test Mode,” on page 9.
When dialing a phone number, the status
display ceases when the first digit of the
phone number is entered. The telephone
number is displayed in the normal manner
as entered. When the
Snd button (or End or
Clr ) is pressed, the status information
display resumes.
The Status Display level allows the phone to
place and receive calls as normal. To enter
this level, press the following key sequence
after supplying power:
• 0 0 * * 83786633
(83786633 spells “TestMode” on the
keypad).
The display will show the following status
information:
The first group indicates:
• Channel number
• RSSI value
• Call-processing mode
The second group indicates:
• SAT frequency
• Carrier state
• Signaling tone state
• Power level
• Voice/data channel mode
• Rx audio state
• Tx audio state
FCN
STO
