© 1998 Motorola, Inc. ii
PREFACE
StarTAC 3000
Cellular Subscriber Group
Preface
Specifications
Table 1: General
Function Specification
Frequency Range 824.03 - 848.98 MHz Tx
869.03 - 893.98 MHz Rx
Channel Spacing 30 kHz AMPS (wide), 10 kHz NAMPS (narrow)
Channels 832/2412
Duplex Spacing 45 Mhz
Frequency Stability + 2.5 ppm AMPS (wide), + 1.0 ppm NAMPS (narrow)
Operating Voltage +4.0 to +5.5 VDC (external connector)
Display 2 lines of 7 digit dot-matrix
RF Power Output 0.6 Watts nominal
Input/Output Impedance 50 ohms (nominal)
Spurious/Harmonic Emissions Complies with Title 47, Part 22 of the FCC Code Regulations
Receive Audio Response 6 dB/octave de-emphasis
Audio Distortion AMPS: Less than 5% at 1 kHz; + 8 kHz deviation
NAMPS: Less than 5% at 1 kHz; + 2.9 kHz deviation
FM Hum and Noise (C-MSG) AMPS: 32 dB below + 8 kHz deviation @ 1 kHz
(C-MSG weighted)
NAMPS: 32 dB below + 2.9 kHz deviation @ 1 kHz
(C-MSG weighted)
Modulation Type F3: +
12 kHz for 100% at 1 kHz, AMPS (wide)
+ 5 kHz for 100% at 1 kHz, NAMPS (narrow)
Transmit Audio Response 6 dB/octave pre-emphasis
Transmit Audio Sensitivity AMPS: + 2.9 kHz deviation (nom.) @ 97 dB SPL input @
1 kHz
NAMPS: +1.5 kHz deviation (nom.) @ 97 db SPL input @
1 kHz
Receive Sensitivity -116 dBm for 12 dB SINAD (C-MSG weighted)
