Motorola StarTAC 3000 Service Manual

RX DISABLE
C136
L113
L101
R136
Q120
R140
R121
R120
R132
C130
R103
R102
R101
C163
C162
C150
L120
L109
L110
L103
C103
L102
R106
Q101
C160
C161
FL101
RX VCO
C106
L312
FL102
FL100
L150
REF 2.75V
Q103
StarTAC 3000: RF Amp-Mixer-IF
S1
J1
Q103
U700-18
L311
881.55MHz
-24.2dBm
page B-3
881.55MHz
-25.4dBm
881.55MHz
-29dBm
881.55MHz
-26.5dBm
881.55MHz
-26.5dBm
991.20MHz
-17.2dBm
991.20MHz
-12.7dBm
109.65MHz
-12.7dBm
page B-18
page B-6
page B-5
VOLTAGE SUPPLIES
Colored boxes represent the area in
which the components are placed.
Channel: 385
TX Freq: 836.55MHz
TX Power Level 2
RX Input Freq: 881.55MHz
RX Input: -20dBm
VCO SIGNAL
RX SIGNAL
Motorola Confidential Proprietary
This manual is Motorola property. Copying or
distribution strictly prohibited without prior written
consent from Motorola and must be returned upon
Motorola's request.
B-4
page B-12
page B-5
