Product Overview B
SVG6x82 Series Wireless Voice Gateway • User Guide
5
Rear Panel
Figure 2 – SVG6x82 Rear View
Table 3 – SVG6x82 Rear Panel Ports & Connectors
PORT NAME DESCRIPTION
TEL 1
TEL 2
• VoIP connection for a single or two-line telephone
• VoIP connection for a single-line telephone
Four one-gigabit Ethernet ports for RJ-45 cable connections
RESET
If you experience a problem, you can push this recessed button to
reset the gateway.
Note: It may take from 5 to 30 minutes for the gateway to find and
lock on the appropriate communications channels.
Coaxial cable connector
+12VDC Power connector
Gateway Label
The SVG6x82 gateway product label is located on the bottom of the gateway. It contains unique gateway
ID information that you may need when contacting your service provider.
