Level 1-2 Service Manual
12-December-2007 32
Exploded View Parts List (W160)
Table 5: W160 (H28) Exploded View Parts List
Part
Number
Item Number Description Specification
001 2240133208W RECEIVER SDR1332F-S2-FB4-G 32OHM AAC
002 7630121254W LCM WD-K1212W-6WLW 128*128 WINTEK
003 2220602207W MIC
ACMG6022-03P28-443 6 AAC
004 3930408022W SPR-VIB 4*L8 1.3V ME9A-MC4 SHICOH
005 2250160815W SPEAKER DMS1608F-S2-05-PC-FB2-G AAC
006 2300H28001W I-ANTENNA H28 ANT+HOLDER EU
051 82E5800003W LABEL
E58 WATERPROOF 3M5559 4mm
251 6910970002W F/WMB 33 H28 GA-129 W/FM
252 6320520001W SMT MMI H28 GS-080 KEYPAD
300 5501650001W ME/PT 33 H28/H28A BLACK
301 31A1H28011W DIAL-ASSY H28-P+R-BLACK-E-21KEY
302 3013H28001W LCMBRAASY H28-METAL FRAME+SPONGE ASSY
303 303FH28001W REC-COV H28-MESH-30*12.82-REC
304 3109H28001W MET-DOME
H28- 4*160g-21KEY
305 3068H28001W GASKET H28-ANT-RUBBER
306 303EH28001W SPK-SPON H28-PORON-12.4*9.4-SPK
307 303FH28002W REC-COV H28-MESH-22*2.9
308 2523H28002W LOW-CASE H28-PC-BLACK
309 3028H28001W RF-COV H28-BLACK
310 3062H28002W NAMEPLATE H28-PC-BLACK
311 8609H28001W ADHESIVE H28-NITTO-106.27*39.01*0.15
312 8609H28002W ADHESIVE H28-D228B-27.6*19.5*0.1
313 303EH28002W SPK-SPON H28-MESH-17.9*9.4-SPK
385 3501645204W SCREW_G FPH-TROX-M1.6 H=4.5 BLA-NYL
