Level 1-2 Service Manual
12-December-2007 8
Specifications
General Functions Specification
Dimensions 113.2mm x 42.0mm x 14.0mm
Weight 84grams (with battery)
LCD Display 65K Color CSTN(MT);Mono STN(LT)
Active Area: 27.264mm x
27.264mm(MT); 28.79 x 28.79 mm(LT)
Hardware pixels: 128 x 128
Band GSM900/1800 or GSM850/PCS1900
Battery 910 mAh Li Ion Battery
Product type BAR type
Antenna Internal Antenna
Frequency Range (EGSM) 880-915 MHz Tx,
925-960 MHz Rx
Frequency Range (DCS) 1710 – 1785 MHz Tx,
1805-1880 MHz Rx
Frequency Range (GSM850) 824-849 MHz Tx,
869-894 MHz Rx
Frequency Range (PCS) 1850-1910MHz Tx,
1930-1990 MHz Rx
Channel Spacing 200KHz
Channels 174 EGSM, 374 DCS,
124 GSM850, 299 PCS
Modulation GMSK at BT=0.3
Transmitter Phase Accuracy 5 Degrees RMS, 20 Degrees peak
Duplex spacing 45MHz EGSM, 95MHz DCS,
45MHz GSM850, 80MHz PCS
Frequency Stability ±0.1PPM of the downlink frequency (Rx)
Operating voltage 3.53V ~4.2V
Average Transmit Current Power Level 5: 175 mA
Power Level 19: 90 mA
Average Standby Current DRX 2: 4.0 mA
DRX 9: 1.9 mA
Temperature Range -10°C to 55°C
Battery Life Talk Time: 250-500 Mins; Stand by Time:
150~300 Hours
Battery Charge Time 4 Hours to 90% of 940mAH capacity
Alert Volume Max 95dB@ 5cm, 0.5 watts input
