Label Name Description
3 LED Status Indicator Red, green, and amber light-emitting diodes indi-
cate operating status.
4 Power button Turn the radio on and off.
5 Push-to-Talk (PTT) button Press or press and hold to execute voice opera-
tions.
6 Menu/Programmable button Press: Access Menu mode.
Press and hold: Access Programmable Function.
7 Volume Up and Volume Down
buttons
Increase and decrease the volume level.
8 Charging Contacts For charging purposes.
9 Liquid Crystal Display (LCD) 132 x 36 display resolutions provides visual infor-
mation about many radio features
3.1
Programmable Buttons
You can program the programmable buttons as shortcuts to specific radio functions through WAVE
portal.
Depending on the duration of a button press, the programmable buttons function differently.
3.1.1
Assignable Radio Functions
The following radio functions can be assigned to the programmable buttons by your dealer.
NOTE: Not all programmable buttons are listed in the following list. Refer to the portal for more
information.
Alert Tones
Allows you to toggle the Alert Tones on and off.
Bluetooth
Allows you to toggle the Bluetooth on and off.
Cellular
Allows you to toggle the Cellular on and off.
Contact List
Allows you to directly access the Contact List.
Do Not Disturb (DND)
Allows you to toggle between on and off.
Keypad Lock
Allows you to toggle the keypad to lock or unlock.
Location
Allows you to toggle the Location on and off.
Mute/Unmute
Allows you to turn Mute Mode on or off.
Menu
Allows you to access the menu features.
MN009326A01-AA
Chapter 3 : Radio Overview
16
