MSI 880GM-E41 series User Manual

2-2
Hardware Setup
MS-7623
Chapter 2
Hardware Setup
MS-7623
Chapter 2
BA
TT
+
SO C K ET AM3
Quick Components Guide
CPU, p.2-4 DDR3, p.2-7
Back Panel,
p.2-10
JPWR1, p.2-9
JPWR2, p.2-9
FDD1, p.2-12
IDE1, p.2-12
SATA1~6, p.2-13
JFP1, JFP2, p.2-13
SYS_FAN1, p.2-14
CPUFAN, p.2-14
JCI1, p.2-14
JCD1, p.2-14 JUSB1~3, p.2-15
JSP1, p.2-16
JAUD1, p.2-15
PCIE, p.2-20
PCI, p.2-20
JTPM1, p.2-16 JBAT1, p.2-17
JCOM1, p.2-17
OC_SW1, p.2-18
