MSI B150M MORTAR ARCTIC User Manual

15
Specifications
Specifications
CPU
Supports 6th Gen Intel
®
Core
™
i3/i5/i7 processors, and
Intel
®
Pentium
®
and Celeron
®
processors for Socket
LGA1151
Chipset
Intel
®
B150 Chipset
Memory
y 4x DDR4 memory slots, support up to 64GB
 Supports DDR4 2133 MHz*
y Dual channel memory architecture
y Supports ECC, un-buffered memory
 ECC UDIMM memory (non-ECC mode)
y Supports Intel
®
Extreme Memory Profile (XMP)**
* Please refer to www.msi.com for more information on compatible memory.
** DDR4 2133 MHz and higher memory modules will only run at maximum of
DDR4 2133 MHz on XMP mode due to Intel
®
chipset limitation.
Expansion Slots
y 2x PCIe 3.0 x16 slots (support x16/x4)*
y 1x PCIe 3.0 x1 slots
y 1x M.2 slot (Key E)
 Supports Wi-Fi module
* The PCI_E3 slot will only run PCIe 3.0 x2 speed when a M.2 SATA storage is
installed in M.2 slot (M2_1), and the PCI_E3 slot will be disabled when a M.2
PCIe module is installed in M.2 (M2_1) slot.
Onboard Graphics
y 1x HDMI
™
port, supports a maximum resolution of
4096x2160@24Hz, 2560x1600@60Hz
y 1x DVI-D port, supports a maximum resolution of
1920x1200 @60Hz
Multi-GPU
y Supports 2-Way AMD
®
CrossFire
™
Technology
Storage
Intel
®
B150 Chipset
y 6x SATA 6Gb/s ports*
y 1x M.2 slot (Key M)*
 Supports up to PCIe 3.0 x4 and SATA 6Gb/s
 Supports 2242/ 2260/ 2280 storage devices
 Supports PCIe 3.0 x4 NVMe Mini-SAS SSD with Turbo
U.2 Host Card**
* SATA1 port will be unavailable when the M.2 SATA module is installed in M.2
slot (M2_1).
** The Turbo U.2 Host Card is not included, please purchase separately.
Continued on next page

MSI B150M MORTAR ARCTIC Specifications

General

Form Factor	Micro ATX
Chipset	Intel B150
Socket	LGA 1151
Memory Slots	4 x DIMM
Maximum Memory	64 GB
SATA Ports	6 x SATA 6Gb/s
USB Ports	6 x USB 3.1 Gen 1, 6 x USB 2.0
Video Outputs	1 x HDMI, 1 x DVI-D, 1 x VGA
RAID Support	RAID 0, 1, 5, 10
Memory Speed	2133 MHz
M.2 Slots	1 x M.2
Audio	Realtek ALC892
LAN	Realtek 8111H
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
