24
Overview of Components
Overview of Components
CPUFAN1
JPWR2
PCI_E1
JTPM1
PCI_E3
PCI_E2
PCI_E4
CPU Socket
DIMM1
DIMM2
DIMM3
DIMM4
JUSB2
JUSB3
(optional)
JFP1
JFP2
SYSFAN2
SYSFAN1
JTBT1
EZ Debug LED
JAUD1
JPWR1
M2-WIFI
JUSB1
JCOM1
SATA5_6
SE1_21-SATA43
JCI1
JBAT1
*JTBT1 is used to connect a speci󰘰c card.
Note: The JTBT1 connector and the PCI_E3 slot can’t be used simultaneously.

Table of Contents

Other manuals for MSI B150M MORTAR

Preview: Assembly Instruction
Assembly Instruction79 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI B150M MORTAR and is the answer not in the manual?

MSI B150M MORTAR Specifications

General IconGeneral
ChipsetIntel B150
Form FactorMicro ATX
SocketLGA 1151
Memory Slots4 x DIMM
Maximum Memory64 GB
Storage Interfaces6 x SATA 6Gb/s
M.2 Slots1 x M.2
Integrated GraphicsDepends on CPU
Memory Speed2133 MHz
PCIe Slots1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
USB Ports6 x USB 3.1 Gen 1, 6 x USB 2.0
Video Outputs1 x HDMI, 1 x DVI-D, 1 x VGA
AudioRealtek ALC892
LANRealtek RTL8111H Gigabit LAN
