MSI B150M MORTAR User Manual

45
BIOS Setup
▶On board LED Control [On]
Enables or disables the actions of onboard LEDs.
[On] Enables the actions of onboard LEDs.
[O󰘯] Disables the actions of power, reset, PCH, audio LEDs.
▶Windows OS Con󰄈guration
Sets Windows 8/ 8.1 detailed con󰘰guration and behaviors. Press <Enter> to enter
the sub-menu.
▶Windows 8.1/ 10 WHQL Support [Disabled]
Enables the supports for Windows 8.1/ 10 or disables for other operating systems.
Before enabling this item, make sure all installed devices & utilities (hardware &
software) should meet the Windows 8.1/ 10 requirements.
[Enabled] The system will switch to UEFI mode to meet the Windows
equirement.
[Disabled] Disables this function.
▶MSI Fast Boot [Disabled]
MSI Fast Boot is the fastest way to boot the system. It will disable more devices to
speed up system boot time which is faster than the boot time of Fast Boot.
[Enabled] Enables the MSI Fast Boot function to speed up booting time. And
the following Fast Boot 󰘰eld will be disabled and 󰘰xed.
[Disabled] Disables MSI Fast Boot.
Important
When MSI Fast Boot is enabled, you can use MSI FAST BOOT application to enter
BIOS setup if needed. Please refer Entering BIOS Setup section for details.
▶Fast Boot [Disabled/ windows7, Enabled/ windows 8.1/ 10]
Enables or disables the fast boot feature for Windows 8.1/ 10. This item will only be
available when MSI Fast Boot is disabled.
[Enabled] Enables the Fast Boot con󰘰guration to accelerate system boot time.
[Disabled] Disables the Fast Boot con󰘰guration.
▶Internal GOP Configuration
Manages the onboard Graphics Output Protocol (GOP). Press <Enter> to enter the
sub-menu. This sub-menu will appear when Windows 8.1/ 10 WHQL Support is
enabled.
▶Secure Boot
Sets the Windows secure boot to prevent the unauthorized accessing. Press
<Enter> to enter the sub-menu. This sub-menu will appear when Windows 8.1/ 10
WHQL Support is enabled.
▶Secure Boot Support [Disabled]
Enables or disables secure boot support.
[Enabled] Enables the secure boot function and allow you to set the secure
boot settings.
[Disabled] Disables this function.

MSI B150M MORTAR Specifications

General

Chipset	Intel B150
Form Factor	Micro ATX
Socket	LGA 1151
Memory Slots	4 x DIMM
Maximum Memory	64 GB
Storage Interfaces	6 x SATA 6Gb/s
M.2 Slots	1 x M.2
Integrated Graphics	Depends on CPU
Memory Speed	2133 MHz
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
USB Ports	6 x USB 3.1 Gen 1, 6 x USB 2.0
Video Outputs	1 x HDMI, 1 x DVI-D, 1 x VGA
Audio	Realtek ALC892
LAN	Realtek RTL8111H Gigabit LAN
