MSI H170M PRO-DH User Manual

33
BIOS Setup
Resetting BIOS
You might need to restore the default BIOS setting to solve certain problems. There
are several ways to reset BIOS:
● Go to BIOS and press F6 to load optimized defaults.
● Short the Clear CMOS jumper on the motherboard.
● Press the Clear CMOS button, on the rear I/O panel. (Only for the motherboard with
clear CMOS button.)
Updating BIOS
Updating BIOS with M-FLASH
Before updating:
Please download the latest BIOS file that matches your motherboard model from MSI
website. And then save the BIOS file into the USB flash drive.
Updating BIOS:
1. Press Del key to enter the BIOS Setup during POST.
2. Insert the USB flash drive that contains the update file into the computer.
3. Selects the M-FLASH tab and click on Yes to reboot the system and enter the
flash mode.
4. Select a BIOS file to perform the BIOS update process.
5. After the flashing process is 100% completed, the system will reboot.
Updating the BIOS with Live Update 6
Before updating:
Make sure the LAN driver is already installed and the internet connection is set
properly.
Updating BIOS:
1. Install and launch MSI LIVE UPDATE 6.
2. Select Manual scan.
3. Check MB BIOS box and click on Scan button.
4. Select the MB BIOS and click on
icon to download and install the latest BIOS
file.
5. Click Next and choose In Windows mode. And then click Next and Start to start
updating BIOS.
6. After the flashing process is 100% completed, the system will restart.

MSI H170M PRO-DH Specifications

General

Form Factor	Micro ATX
Socket	LGA 1151
Chipset	Intel H170
Memory Type	DDR4
Memory Slots	4
Maximum Memory	64 GB
Memory Speed	2133 MHz
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
SATA 6Gb/s	6
M.2 Slot	1
USB 3.0 Ports	6
LAN	Realtek RTL8111H Gigabit LAN
Audio	Realtek ALC887 Codec
Video Outputs	1 x HDMI, 1 x DVI-D, 1 x VGA
USB 2.0 Ports	6 (4 on the front, 2 on the back)
