MSI MEGA ePower 200AV+ User Manual

21
Appendix D
Contact Information
For help with the Installation or operation of the MSI Mega ePower 200AV+ adapter,
please contact us.
Technical Support :
for all MSI Products w/o Notebooks
Tel.: 01805-215 521 (0,12 €/Min. german landline!)
Outside Germany pleas call: 0049-1805-215 521
Monday - Friday from 8:00 to 18:00 CET
Support MSI-Contact :
http://www.msi-computer.de/support/sa_idx.php
Website:
www.msi-computer.de

MSI MEGA ePower 200AV+ Specifications

General

Chipset	Intellon INT6400/INT1400
LED’s	Power Ethernet: Ethernet Link and Activity Data: PLC Link and Activity
Push Button	Reset: Restore the default factory parameter Security: Set up network password automatically
Protocol	HomePlug AV 1.0 Co-exists with existing HomePlug 1.0
PLC Rate	200Mb
Modulation Band	2-30MHz
Modulation Schemes	Supports1024/256/64/16/8-QAM, QPSK, BPSK and ROBO
Encryption	128 AES
System Support	Windows 98SE, 2000, ME, XP 32/64 bit and Vista 32/64bit
Outlet current	220VAC 16A Maximum，110VAC 20A Maximum
Consumption	3.5W
Input Rating	100-240 VAC, 50/60Hz
Filter characteristics	-22 dB to -45 dB
Certifications	CE, UL, FCC Part 15 Class B
Green Standard	RoHS
Operating Temperature	0º to 45º C
Storage Temperature	-20 º to 70 º C
Operating Humidity	10% to 90% Non-condensing
Storage Humidity	5% to 90% Non-Condensing

Weight and Dimensions

Physical Characteristics	L×W×H: 130.5mm×69mm×79mm
Weight	233g
